CL-30 Standard Steel Blade

Home Application area Gravure printing CL-30 Standard Steel Blade

CL-30 Standard Steel Blade

Features:

·Made with high quality cold-rolling carbon steel,provided by Germany ZAPP

·No start-up time due to the technically advanced lamella profile

·The specially polished blade guarantees smooth and better sharp doctoring

·Plus of CL-20, which has more stable and better performance, after our customers’ test, its service life in black ink can reach about 180,000m.

Gravure printing, Stainless steel doctor blade, ≤250M/Min, Featured Products2018-06-04d80 Tags: standard steel doctor blade, doctor blade for gravure printing

Description

CL-30 Standard Steel Blade

Configuration

Brand DEKEJIE Category  Stand steel
Type CL-30 Printing speed ≤250m/min
Material thickness 0.152-0.203mm Packing 100M/box
Suggested application Normal gravure printing
Standard size 10,30,40,50,60mm
4037YR
Material composition
C Mn Si P S Cr
1.00 0.30 0.25 max. 0.025 max. 0.025 1.5
Hardness
580 – 600 HV
Straightness
max. 0.15mm/1m
Tensile strength
1850 -2000 Mpa
